Product Details
Place of Origin: CHINA
Brand Name: Hengcheng
Certification: ISO Patent Certificate High-Tech Product Certificate
Model Number: HVM1250 HVM1300 HVM1500 HVM1700 HVM1900 HVM2400 HVM2500 HVM2800
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard shipping packaging
Delivery Time: 60 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5 sets/month
Name: |
High Efficiency Limestone Vertical Mill |
Motor Type: |
AC Motor |
Capacity: |
6~80 T/h |
Condition: |
New |
Key Selling Points: |
Energy Saving |
Incoming Material Moisture: |
≤5% |
Fineness Of Limestone Powder: |
325 Meshes |
Main Motor Power: |
110-1250kw |
Main Materials: |
Limestone,Clay,Gypsum,Fly Ash,Slag |
Name: |
High Efficiency Limestone Vertical Mill |
Motor Type: |
AC Motor |
Capacity: |
6~80 T/h |
Condition: |
New |
Key Selling Points: |
Energy Saving |
Incoming Material Moisture: |
≤5% |
Fineness Of Limestone Powder: |
325 Meshes |
Main Motor Power: |
110-1250kw |
Main Materials: |
Limestone,Clay,Gypsum,Fly Ash,Slag |
325 Mesh Vertical Roller Mill For Limestone, Calcite, Barite, Dolomite And Feldspar
Description
Cement raw material, limestone vertical mill is a combination of fine crushing, drying, grinding, powder selection and transportation. It has the advantages of small footprint, simple process flow, high grinding efficiency, low energy consumption, low noise, large drying capacity, The product has the characteristics of easy adjustment of fineness, no dust pollution, convenient maintenance and reliable operation. Especially in the large-scale grinding process, it fully meets the needs of customers, and the main technical and economic indicators reach a certain level.
Cement raw materials, limestone vertical mills are all in Hefei Hengcheng Technology, and the mills can be customized according to different production parameters.
Cement raw material, limestone vertical mill is Hefei Hengcheng Technology to solve the technical problems of low output and high energy consumption of industrial mills, absorb technology and combine Hefei Hengcheng Technology's many years of mill design and manufacturing concepts and market demand, after years of painstaking design Improved large grinding equipment.
Technical Data
| Model | HVM1250 | HVM1300 | HVM1500 | HVM1700 | HVM1900 | HVM2400 | HVM2500 | HVM2800 |
| Grinding Table Median Diameter(mm) | 1250 | 1300 | 1500 | 1700 | 1900 | 2400 | 2500 | 2800 |
| Capacity(t/h) | 6~9 | 9~13 | 15~20 | 24~32 | 26~35 | 36~45 | 45～58 | 56~80 |
| Material Moisture | ≤5% | |||||||
| Limestone Powder Fineness | 325 mesh (44um) 90% passed | |||||||
| Main Motor Power(kw) | 110/132 | 185/200 | 250/280 | 355/400 | 450/500 | 450/500 | 710/800 | 1120/1250 |
Re:The data based on Mohs'hardness 3-4 material
Limestone Bond Index≤13kwh/t
【Main Features Of The Product】
1. High efficiency and energy saving:
High grinding efficiency and low energy consumption, compared with ball mills, the energy consumption is 40%-50% lower;
Large single machine production capacity
2. Low comprehensive investment cost:
It integrates crushing, drying, grinding and conveying, with simple process flow, less system equipment, compact structure and layout, and small footprint, which is only 50% of the ball mill.
3. Easy maintenance and low operating cost:
Maintenance work is very convenient;
The service life of wear-resistant materials;
High degree of automation and easy operation
4. Stable product quality:
The product quality is stable; the product particle shape is uniform, the particle size distribution is narrow, the fluidity is good, and the product adaptability is strong.
5. High reliability
Reliable sealing and excellent explosion suppression performance.
6. Environmental protection:
The whole system of HVM vertical mill has small vibration and low noise; no dust spillage
