Vertical Roller Mill Energy-Saving Limestone Powder Grinding Equipment Vertical Mill Manufacturer

Vertical Roller Mill Energy-Saving Limestone Powder Grinding Equipment Vertical Mill Manufacturer

Description

The vertical grinding machine plays a crucial role in the grinding production line and has a wide range of applications. It can be divided into three types based on its volume: large, medium, and small. The application range is selected according to its actual situation. The main differences among the three types of equipment are power, production capacity, and price. Other design ideas, operation instructions, precautions, and so on are consistent.

The HVM vertical grinding machine can process materials such as ferrite, slag, slag, cement, diamond, iron ore, chromium ore, manganese ore, gold ore, copper ore, aluminum ore, lead zinc ore, tantalum niobium ore, polymetallic ore, nickel ore, bauxite, silicon carbide, titanium dioxide, talc, bentonite, calcite, kaolin, graphite, mica, wollastonite, feldspar, dolomite, pyrophyllite, quartz sand, fluorite, limestone, organic silicon, lithium ash, etc Shale, volcanic ash, coal, etc.

Limestone Vertical Mill Working principle:

The electric motor drives the grinding disc to rotate through the reducer, and the material falls into the center of the grinding disc from the feeding port. At the same time, hot air enters the grinding chamber from the inlet. Under the action of centrifugal force, the material moves towards the edge of the grinding disc and is crushed by the grinding roller when passing through the circular groove on the grinding disc. The crushed material is carried up by the high-speed airflow at the wind ring at the edge of the grinding disc, and large particles directly fall onto the grinding disc for re grinding. When the material in the airflow passes through the dynamic and static separator, under the action of the rotating rotor, the coarse powder falls onto the grinding disc for re grinding, and the qualified fine powder is discharged with the airflow, Collecting in the powder collection device is the product. Materials containing moisture are dried during contact with hot gases to achieve the required product moisture.


Advantages and characteristics of limestone ultrafine vertical grinding machine:
1. Vertical grinding machines have advantages such as high grinding efficiency, low power consumption, large feed particle size, easy adjustment of product fineness, simple equipment process flow, small footprint, low noise, low dust, easy use and maintenance, low operating costs, and low consumption of wear-resistant materials.
2. The comprehensive investment cost of limestone vertical mill is low.
3. Easy maintenance and low operating costs.
4. High grinding efficiency.
5. Stable production and quality.
6. High reliability.
7. Environmental protection.
8. High degree of automation.

Enterprise advantages and characteristics
① Leading in technology, with years of in-depth research on various domestic and foreign brands of vertical mills and pneumatic conveying systems, possessing independent intellectual property rights in the design and manufacturing technology of vertical mills and pneumatic conveying systems, and more than 10 years of professional manufacturing experience in vertical mills;
② Professional manufacturing, specialized production of vertical grinding and pneumatic conveying equipment and their supporting products, all machine tools and equipment are based on meeting the production requirements of these equipment;
③ We have over 4500 square meters of specialized workshops and machine tools for producing vertical mills;
④ Excellent and timely after-sales service, with a skilled and responsible installation and debugging team.

Technical Data

Re:The data based on Mohs'hardness 3-4 material

      Limestone Bond Index≤13kwh/t
