Product Details
Place of Origin: CHINA
Brand Name: Hengcheng
Certification: ISO Patent Certificate High-Tech Product Certificate
Model Number: HVM2500 HVM2800 HVM3400 HVM4200 HVM4500 HVM4800 HVM5100 HVM5600
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard shipping packaging
Delivery Time: 60 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5 sets/month
Features: |
Low Energy Consumption |
Name: |
Gypsum Grinding Mill |
Type: |
Vertical Roller Mill |
Capacity(t/h): |
240~300 |
Machinery Test Report: |
Provided |
Applicable Industries: |
Energy & Mining |
Raw Meal Fineness: |
R0.08＜14% |
Dimension(L*W*H): |
According To Different Model |
Grinding Table Median Diameter(mm): |
2500,2800,3400,3700,4200,4500,4800,5100,5600 |
Features: |
Low Energy Consumption |
Name: |
Gypsum Grinding Mill |
Type: |
Vertical Roller Mill |
Capacity(t/h): |
240~300 |
Machinery Test Report: |
Provided |
Applicable Industries: |
Energy & Mining |
Raw Meal Fineness: |
R0.08＜14% |
Dimension(L*W*H): |
According To Different Model |
Grinding Table Median Diameter(mm): |
2500,2800,3400,3700,4200,4500,4800,5100,5600 |
High Efficiency Pulverizing Mill Marble Limestone Gypsum Barite Powder Making Production Grinding Mill
Description:
The application of gypsum powder has a long history. In the early days, it was simply used to make chalk, putty, tofu and handicrafts. At present, it has been widely used in many fields such as construction, building materials, power plants, papermaking, paint, food, and medicine. The main chemical composition of gypsum is calcium sulfate hydrate.
Gypsum is a versatile industrial and construction material. It can be used in cement retarder, gypsum building products, model making, medical food additives, sulfuric acid production, paper filler, paint filler, etc. The microporous structure and heating dehydration of gypsum and its products make it have excellent sound insulation, heat insulation and fire resistance.
【Advantages Of Vertical Mill】
1. Environmental protection: the whole system has small vibration, low noise, full negative pressure operation, and less dust emission;
2. Reliable performance: The mill adopts a grinding roller limit device and a new type of grinding roller sealing device, which has more reliable sealing and better explosion suppression performance;
3. High powder yield: high grinding efficiency and large single-machine production capacity;
4. High degree of automation: PLC automatic control system is adopted, which can realize remote control and easier operation.
Specifications And Technical Parameters Of HVM Gypsum Vertical Mill
| Model | HVM2500 | HVM2800 | HVM3400 | HVM3700 | HVM4200 | HVM4500 | HVM4800 | HVM5100 | HVM5600 |
| Grinding Table Median Diameter(mm) | 2500 | 2800 | 3400 | 3700 | 4200 | 4500 | 4800 | 5100 | 5600 |
| Capacity(t/h) | 85-100 | 130-160 | 190-240 | 240-300 | 320-400 | 400-500 | 440-550 | 550-670 | 600-730 |
| Raw Material Moisture | ＜10% | ||||||||
| Raw Meal Fineness | R0.08＜12% | R0.08＜14% | |||||||
| Raw Meal Moistrue | ≤1% | ||||||||
| Main Motor Power(kW) | 800/900 | 1120/1250 | 1800/2000 | 2500/2800 | 3150/3350 | 3800/4200 | 4200/4500 | 5000/5400 | 5600/6000 |
| Illustrate |
Re:Raw materials bond index≤13kWh/t |
||||||||
The vertical mill integrates drying, grinding, grading and conveying, with high grinding efficiency, low power consumption, large feeding particle size, easy adjustment of product fineness, simple equipment process, small footprint, low noise, It has the characteristics of small dust, easy use and maintenance, low operating cost, and low consumption of wear-resistant materials.
Grindable Material
