Product Details
Place of Origin: CHINA
Brand Name: Hengcheng
Certification: ISO Patent Certificate High-Tech Product Certificate
Model Number: HVM2500 HVM2800 HVM3400 HVM4200 HVM4500 HVM4800 HVM5100 HVM5600
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard shipping packaging
Delivery Time: 60 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5 sets/month
Name: |
Vertical Grinding Mill Machine Mineral Grinder Gypsum Powder Production Line |
Type: |
Vertical Grinding Roller Mill |
Capacity: |
85-730(t/h) |
Power: |
800-6000(kw) |
Fineness: |
80 μmR 12-14% |
Raw Material Moisture: |
＜10% |
Dimension(L*W*H): |
L*W*H): Customizable |
After Sale Service: |
Techniacal Support |
Color: |
Customer Request |
Name: |
Vertical Grinding Mill Machine Mineral Grinder Gypsum Powder Production Line |
Type: |
Vertical Grinding Roller Mill |
Capacity: |
85-730(t/h) |
Power: |
800-6000(kw) |
Fineness: |
80 μmR 12-14% |
Raw Material Moisture: |
＜10% |
Dimension(L*W*H): |
L*W*H): Customizable |
After Sale Service: |
Techniacal Support |
Color: |
Customer Request |
High Pressure Vertical Grinding Mill Machine Mineral Grinder Gypsum Powder Production Line
Description:
【Product Introduction Of Gypsum Vertical Mill】
HVM series vertical grinding mill is a high-efficiency and energy-saving advanced grinding equipment integrating drying, grinding, grading and conveying, developed by Hengcheng Company through learning and introducing foreign advanced technology and after more than 20 years of painstaking research and development.
【Application Field】
Grinding and processing of non-flammable and explosive materials with humidity within 6% and Mohs hardness below 7 in the fields of building materials, chemical industry, metallurgy, paint, paper, rubber, medicine, food, etc.
【Applicable Materials】
Kaolin, barite, fluorite, talc, water slag, lime calcium powder, wollastonite, gypsum, limestone, phosphate rock, marble, potassium feldspar, quartz sand, bentonite, manganese ore and other hardness Mohs Materials below grade 7
Specifications And Technical Parameters Of HVM Gypsum Vertical Mill
| Model | HVM2500 | HVM2800 | HVM3400 | HVM3700 | HVM4200 | HVM4500 | HVM4800 | HVM5100 | HVM5600 |
| Grinding Table Median Diameter(mm) | 2500 | 2800 | 3400 | 3700 | 4200 | 4500 | 4800 | 5100 | 5600 |
| Capacity(t/h) | 85-100 | 130-160 | 190-240 | 240-300 | 320-400 | 400-500 | 440-550 | 550-670 | 600-730 |
| Raw Material Moisture | ＜10% | ||||||||
| Raw Meal Fineness | R0.08＜12% | R0.08＜14% | |||||||
| Raw Meal Moistrue | ≤1% | ||||||||
| Main Motor Power(kW) | 800/900 | 1120/1250 | 1800/2000 | 2500/2800 | 3150/3350 | 3800/4200 | 4200/4500 | 5000/5400 | 5600/6000 |
| Illustrate |
Re:Raw materials bond index≤13kWh/t |
||||||||
HVM series vertical mill has the advantages of high grinding efficiency, low power consumption, large feeding particle size, easy adjustment of product fineness, simple equipment process, small footprint, low noise, small dust, easy use and maintenance, and operating costs. It has the advantages of low consumption and low consumption of wear-resistant materials.
It can be widely used in electric power, metallurgy, cement, chemical industry, non-metallic minerals and other industries. The material is grinded.
【Product Advantages Of Gypsum Vertical Mill】
1. High efficiency and energy saving:
2. Easy maintenance and low operating cost:
3. Low comprehensive investment cost: it integrates crushing, drying, grinding and conveying, with simple process flow, less system equipment, compact structure layout, and small footprint, which is only 50% of that of ball mill.
4. Stable product quality:
5. High reliability:
6. Environmental protection:
7. High degree of automation: PLC automatic control system is adopted, and remote control can be realized, which is easy to operate, easy to maintain and reduce labor costs.
【After-sales Service】
From planning site to design drawings, from technical training to installation and commissioning; production lines ranging from tens of millions to tiny gears, no matter where you are, just a phone call or an email, within 24 hours, you will be Will get our response and help.
